Growatt 9.6kW THOR 09AS-P US 40Amp Smart AC EV Charger | Compatible with All Brands EVs

Growatt THOR 9.6kW Level 2 EV Charger (THOR 09AS-P US) — 40A, Wi-Fi, RFID, PV Linkage, NEMA 4X

Charge faster, smarter, and greener. The Growatt THOR 9.6kW Level 2 EV Charger (THOR 09AS-P US) delivers 40A of reliable AC charging for homes and businesses, with built-in Wi-Fi/App control, RFID activation, and PV Linkage to prioritize surplus solar power through the GroHome ecosystem. Outdoor-ready with advanced protection and UL/CSA certifications, it’s an easy way to maximize solar self-consumption and cut your energy costs.

Highlights

• Level 2, 240V / 40A (9.6kW) for fast, dependable charging

• SAE J1772 (Type 1) connector—compatible with most EVs; Tesla requires adapter

• PV Linkage (GroHome) to dynamically use surplus solar and boost self-consumption

• Smart controls: Plug & Play, RFID card, and mobile app (LAN / Wi-Fi / optional 4G)

• Smart load balancing to protect circuits and manage multiple chargers

• Outdoor/indoor rated enclosure (NEMA Type 4X) for harsh environments

• Comprehensive safety: Type A RCD + 6mA DC fault protection

• UL2594, UL2231, UL1998, CSA-C22.2 certified

• 3-year warranty backed by Growatt

Why it’s great for solar homes & small businesses

Pair the THOR with your PV system and GroHome. PV Linkage mode prioritizes surplus solar for EV charging, helping you use more of your own clean energy and reduce grid draw during sunny hours. Multiple working modes—Fast, PV Linkage, Off-Peak, Load Balancing—let you tailor charging to your tariff and lifestyle.

Technical Specifications

Manufacturer: Growatt

Type: AC EV Charger (Level 2)

Model: THOR 09AS-P US

Max Output Power: 9.6kW

Max Output Current: 40A

Input Voltage: 240V

Charging Interface: SAE J1772 (Type 1)

Connection: Plug

Cable Length: 23 ft (7 m)

Networking/Control: LAN, Wi-Fi (optional 4G), App control, RFID, Plug & Play

Working Modes: Fast / PV Linkage / Off-Peak / Load Balancing

Enclosure Rating: NEMA Type 4X (outdoor/indoor)

Protection: Type A RCD + 6mA DC fault protection

Dimensions (W × H × D): 9.68 × 15 × 6.06 in (246 × 382 × 154 mm)

Weight: 20.9 lb (9.5 kg)

Certifications: UL2594, UL2231, UL1998, CSA-C22.2

Warranty: 3 Years

What you can do from the app

• Start/stop charging and set schedules (off-peak, solar-first)

• Monitor real-time power, energy, and session history

• Manage access with RFID and user permissions

• Balance loads across multiple chargers

Specifications: Download

Manuals & Guides: Download

Certificates: Download
